Post #867
774
SplitKBD Свежий прототип с подставкой под запястье (видео). У клавиатуры появилось название - ShapeKey46 Source: Twitter #pictures
Source: Twitter
#pictures
#pictures
- ❤🔥 3
- 👾 1
Post #866
827
Lintilla by ctranstrum
42 key wireless split ergo keyboard with aggressive pinky stagger, splay, and "reachy" thumbs
Features
* Seeed Studio XIAO BLE microcontroller
* Choc v1 hotswap switches
"Relaxed" (18.5x18) choc spacing: a compromise between MX (19x19) and choc (18x17)
* 7mm low-profile "snug sandwich" case with no exposed components on top or bottom
* RGB LED status visible on the top of the case
* Wireless-first design using ZMK firmware (including ZMK Studio)
* Jumperless reversible PCB designed with ergogen
* Soldering is simple: SMD components all on a single side of the board for each half
* Internal space (5.4 x 24 x 34 mm) for a "large" 502030 250mAh battery
* Licensed under the CERN Open Hardware License v2
* All source files available, so you can tweak the design if needed
GitHub
#choc • #xiao • #ble • #zmk • #splay • #42key
42 key wireless split ergo keyboard with aggressive pinky stagger, splay, and "reachy" thumbs
Features
* Seeed Studio XIAO BLE microcontroller
* Choc v1 hotswap switches
"Relaxed" (18.5x18) choc spacing: a compromise between MX (19x19) and choc (18x17)
* 7mm low-profile "snug sandwich" case with no exposed components on top or bottom
* RGB LED status visible on the top of the case
* Wireless-first design using ZMK firmware (including ZMK Studio)
* Jumperless reversible PCB designed with ergogen
* Soldering is simple: SMD components all on a single side of the board for each half
* Internal space (5.4 x 24 x 34 mm) for a "large" 502030 250mAh battery
* Licensed under the CERN Open Hardware License v2
* All source files available, so you can tweak the design if needed
GitHub
#choc • #xiao • #ble • #zmk • #splay • #42key
- 🔥 3
Post #865
659
Post #860
798
Post #857
601
Gateron KS-33 Low Profile Red Silent 2.0 Mechanical Switches
Specs:
* Type: Linear
* Operating Force：45±15 gf
* Pre-Travel：1.7mm
* Total Travel：3.0±0.2 mm
* Stem: POM
* Top Housing: PC, Transparent
* Bottom Housing: Nylon, Black
* LED Support: SMD
* Pre-Lubed: Yes
* Pins：3-Pin/5-Pin
[In Stock] Product page
#news
Specs:
* Type: Linear
* Operating Force：45±15 gf
* Pre-Travel：1.7mm
* Total Travel：3.0±0.2 mm
* Stem: POM
* Top Housing: PC, Transparent
* Bottom Housing: Nylon, Black
* LED Support: SMD
* Pre-Lubed: Yes
* Pins：3-Pin/5-Pin
[In Stock] Product page
#news
Post #856
616
SplitKBD [IC] Link Split Ergo A Column-staggered split keyboard based on the Sofle58 v2 Specs & Features: * Hotswappable OLED screen * Rotary encoder module * Hotswap MX PCBs * USB-C interconnect * Aluminum OLED cover * Tray/gasket mount * 1.2mm PCB * 0° angle case…YouTube The Link Split Ergo BUILD SPECS: Link Split Ergo — https://cannonkeys.com/products/link Switches — Astral Switches Stabs — N/A Keycaps — GMK Tribal Note: Some of these are affiliate links and i get a kick back! They help support my channel. LEARN HERE: ▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀▀…
