РИСАТЕНО (RISATENO) by aroum

РИСАТЕНО (RISATENO) - created as a rethinking of ARTSEY for the Russian language. 10 keys, two for each finger.
The name is made up of letters on the main layer. The letters on the base layer are selected according to the frequency.

Features
* 10 keys, Kailh Choc V1 switches
* Choc spacing
* Direct pins
* Wireless(optional)
* Per switch RGB(optional)
* Power switch for wireless controllers (optional)

#choc • #promicro • #nrfmicro • #qmk • #zmk • #kle • #diodeless • #rgb • #10key

Jorian840 by krikun98

44-key wireless split keyboard in a 100x100 mm PCB.
Two main versions are available with plenty of supported switches.
Plates and bottoms are to be cut from metal, acryllic or dual-layered plastic.

Features
* Wireless via Holyiot 18010 modules
* Fully-featured ZMK split
* Uses either 233350 310 mAh, LIR2032 40 mAh or CR2032 220 mAh (non-rechargeable) batteries
* Charger on/off switch (for non-rechargeable batteries)
* Proper case support
* Adjustable pinky stagger in the solder version
* Can be built with 7 or 8 mm. standoffs even with the rechargeable battery under the PCB

#mx • #alps • #omron • #ble •#zmk • #cr2032 • #44key

Clavert by thlintw

Vertical, wireless, ergonomic split keyboard
Gallery

#mx • #nrfmicro • #zmk • #encoder • #handwired • #3d • #70key

Ferricy by icyphox

Ferricy is a slightly modified version of the Ferris Sweep, sporting a more industrial look with sharper edges.

Features
* Ferricy MX based on the Sweep MX Bling.
* Ferricy Choc based on the Sweep Half-Swept.
* Tenting puck support has been removed (I have no use for it).
* Squared-off edges (plates modified accordingly).
* Larger holes in the PCB for M2 standoffs to pass through.
* The stupid Rust crab is gone.

#choc • #mx • #nrfmicro • #qmk • #zmk • #34key

kpukboard by kriku

Bluetooth keyboard - printed circuit board design.
Kpukboard is a 38 key column-staggered choc split keyboard. It meant to be used with a seeeduino xiao ble. As thin as possible with kailh choc mini switches
Gallery

#chocmini • #ble • #xiao • #splay • #38key

Charybdis by Bastardkb

An ergonomic keyboard with integrated trackball. Engineered to be a full mouse replacement solution with high-quality, custom-developed components.

There are 4x6 and 3x5 Nano versions

#mx • #promicro • #qmk • #trackball • #rgb • #35key • #56key • #3d

Musubi by wontaeyang

Musubi is a 38 key split keyboard using Kailh X switches and Seeeduino Xiao. This keyboard started with dust keyboard as a base and adjusted with customized layout and design elements from my favorite keyboards:
- dust by Hazel
- TOTEM by GEIST
- Dilemma by BastardKB

Features
* Reversible PCB
* Column stagger with splay
* 3x5 layout with 4 additional keys (three thumb, 1 pinky)
* Slim build (measured from keycap to bottom)
✓ without case 6.7 mm
✓ with case 9.7 mm
* Tenting puck support

#kailhx • #rp2040 • #xiao • #qmk • #splay • #38key

KLOR by GEIST

KLOR is a 36-42 key column-staggered split keyboard. It supports a per key RGB matrix, encoders, OLED displays, haptic feedback, speakers, a Pixart Paw3204 trackball, the SplitKB tenting puck and four different layouts, through break off parts.

Features
* Per key RGB matrix
* Encoders
* (kind of hidden) OLED displays
* Haptic feedback
* Speakers
* Pixart Paw3204 trackball
* Four different layouts, through brake off parts
* SplitKB tenting puck support.

KS-27 mod

#mx • #promicro • #kb2040 • #nrfmicro • #qmk • #zmk • #kmk • #ble • #encoder • #display • #oled • #haptic • #speaker • #trackball • #splay • #36key • #42key • #rgb

giraffe36 by sboysel

A 36 key split keyboard with "long-necked" thumb clusters. Wired, powered by Raspberry Pi Picos, diodeless. Inspirations include Ferris Sweep / sweep36, draculad, samoklava, piantor.

Goals
* Simplicity
* Declarative design (ergogen and specifically, my fork)
* 5x3+3 wired split
* Soldered MX to build plateless
* Diodeless
* Lowered thumb cluster comfortable to my hands
* To learn PCB design!

#mx • #rp2040 • #kmk • #diodeless • #36key

Fifi by raychengy

The Fifi keyboard, named after my 🐶, is a split keyboard with 3x5 column staggered keys and 3 thumb keys, based on foostan's mini-crkbd schematic and thomasbaart's kyria layout.

#mx • #promicro • #qmk • #rgb • #36key

Pinky3 by tamanishi

A split 3 x 7 vertically staggered keys and 4 thumb keys keyboard.

#choc • #mx • #promicro • #nrfmicro • #qmk • #zmk • #ble • #50key

Nijuni by krikun98

The Nijuni (formerly known as the RT-22) is a 44-key split keyboard inspired by the Jian (stagger, pinky and controller footprint) and the Jorne (thumb cluster and wiring).

It was originally conceived by DwarZ, however, V0.1 had a screw placement issue that restricted it to Kailh BOX-style switches. V0.2 is trouble-free, and prototypes have already been tested.

Features
* Wireless focus - battery footprint, power switches and no LEDs in sight
* Uses Jorne firmware - so QMK and ZMK support
* MX or Alps soldered or MX hotswap support in a single reversible PCB
* 6 column version also available for 100x150 PCB promos.

#mx • #alps • #promicro • #nrfmicro • #qmk • #zmk • #ble • #36key • #42key • #44key

Draculad by MangoIV

QMK-powered 34-36 key split keyboard

Features
* 36 keys, two of them can be replaced by rotary encoders making it support 34-36 keys and 2-4 encoders.
* Bright RGB Underglow with WS2812b LEDs
* One SSD1306 OLED per side
* Support for the pimoroni trackball
powered by QMK-firmware (Firmware has been merged and can be found on the QMK master)
* Aggressive pinky stagger similar to the Kyria but with a slightly alternative thumb cluster to raise comfort for large hands
* Support for MX and Kailh choc v1 switches
* Files for fr4 plate and acrylic bottom plate as well as OLED window

#choc • #mx • #promicro • #qmk • #trackbal • #display • #oled • #encoder • #rgb • #34key • #36key

Torn by rtitmuss

The split keyboard kit made with through hole components. The design has been inspired by the Corne, Plaid and Discipline keyboards.

#choc • #mx • #qmk • #encoder • #display • #oled • #42key • #44key

Wubbo by cacheworks

A wireless 34 key keyboard with the top pinky keys moved to the 6th column.

#choc • #ble • #zmk • #splay • #34key

Hillside by mmccoyd

Family of split ergonomic keyboards with three rows of five or six keys, aggressive column stagger, a generous thumb arc and most have a partial bottom utility row

Features
* Choc-spaced keys, aggressive stagger, five thumb keys
* Break-off outer pinkie column
* Tenting puck support
* QMK and wireless ZMK firmware
* Nice!nano battery power switch
* Encoder support
* Haptic feedback header
* Underglow from four or five SK6812-MINI-Es
* Reversible PCB
* Detailed BOM and default keyboard rationale.
* SMT diodes, resistors, capacitors, and reset switch

#choc • #nrfmicro • #promicro • #ble • #qmk • #zmk • #encoder • #haptic • #rgb • #splay • #46key • #48key • #52key • #56key

Avalanche by vlkv

The Avalanche keyboard is an ergonomic split keyboard with 4x6 (or 3x6 if you break off the 'digits' row) column staggered keys, 5 thumb keys, 1 additional key for the pinky (break off-able too) and 2 additional keys for the index finger (64 keys total).

#mx • #promicro • #qmk • #display • #oled • #encoder • #rgb • #splay • #48key • #50key • #64key

Piantor by beekeeb

The keyboard name Piantor (Pi-antor) is the portmanteau of "Pico" and "Cantor". As the name suggested, it has the same strong column stagger layout as the Cantor Keyboard created by u/diepala and is powered by Rasyberry Pi Pico or other compatible RP2040 boards (e.g. WeAct RP2040).

Features
* RP2040 MCU: Low cost yet powerful microcontroller. You can enable a lot of features and layers without worrying about the firmware size limit. Rasyberry Pi Pico is reliable and easy to source too.
* Breakable pinky column: Easily convert the PCB from a 42-key to 36-key layout
* Hotswap (Kailh Choc v1 Hotswap Sockets) or soldered-in low profile choc switches: Experiment with different key switches with the hotswap sockets, or solder the key switches for a more stable build.
* Cantor layout - Ergonomic strong column staggering for short pinkies.
* Diodeless - A more robust build with fewer things to solder or break.

#choc • #rp2040 • #qmk • #kmk • #diodeless • #36key • #42key

DASBOB by GrooveBob

36 Key Diodeless Split Choc Keyboard wit a Buzzer

#choc • #promicro • #nrfmicro • #qmk • #zmk • #diodeless • #display • #oled • #buzzer • #splay • #36key

Rae-dux by andrewjrae

The rae-dux is a 36-key (diodeless!), wireless keyboard inspired by the Architeuthis Dux. This project used to use the samoklava workflow, however the auto-router had troubles with the splay, currently I just use the image generating parts of the samoklava workflow.

Build Guide

#choc • #nrfmicro • #ble • #zmk • #diodeless • #splay • #36key
